Orange Pi One A7 Quad Core CPU (1.6GHz, 512MB, DDR3) (101765)


Orange Pi  One is an open-source single-board computer. It can run Android, Ubuntu, Debian OS etc, Raspberry Pi compatible. It uses the AllWinner H3 SoC, which has 512MB DDR3 SDRAM. Orange Pi One is not only a mini PC, but also a hardware that support engineers, makers and electronic hobbyist to create geek things that you can image, build a smart device with no limitation. It is a super low cost but very powerful solution for your project.

The Orange Pi One has 40 pin headers, which is fully compatible with Raspberry pi B+.

What can I do with Orange Pi One?

You can build
A computer
A wireless server
Music and sounds
HD video player
A speaker
Android Device


  • CPU: H3 Quad-core Cortex-A7 H.265/HEVC 4K
  • GPU: Mali400MP2 GPU @600MHz, Supports OpenGL ES 2.0
  • Memory (SDRAM): 512MB DDR3 (shared with GPU)
  • Onboard Storage: TF card (Max. 64GB) / MMC card slot
  • Onboard Network: 10/100M Ethernet RJ45
  • Video Input: A CSI input connector Camera:
    Supports 8-bit YUV422 CMOS sensor interface
    Supports CCIR656 protocol for NTSC and PAL
    Supports SM pixel camera sensor
    Supports video capture solution up to 1080p@30fps
  • Video Outputs: Supports HDMI output with HDCP

    Supports HDMI CEC
    Supports HDMI 30 function
    Supports simultaneous output of HDMI

  • Power Source: DC input can supply power, but USB OTG input don’t supply power
  • USB 2.0 Ports: Only One USB 2.0 HOST, one USB 2.0 OTG
  • Low-level peripherals: 40 Pins Header,compatible with Raspberry Pi B+
  • Supported OS: Android Ubuntu, Debian, Rasberry Pi Image
  • Product dimension: 69 mm × 48mm
  • Weight: 36g


How to get started with the Orange Pi One

Write a review

Note: HTML is not translated!
    Bad           Good

Orange Pi One A7 Quad Core CPU (1.6GHz, 512MB, DDR3) (101765)

  • Product Code: 101765
  • Availability: SOLD OUT
  • $19.99
  • 10+$15.00
  • 30+$14.00
  • 50+$13.00

Available Options

Tags: modules
