Introduction:
This is the best digital oscilloscope for a small budget with logic-analyzer we found on the market.
Large display, easy user interface and fast enough for most applications.
The 2 analog channels plus 16 logic channels makes mixed signal debug easier.
Perfect for beginners and education.
See the related products for other oscilloscopes.
Features:
- 2 analog channels, 100MHz bandwidth, 1GSa/s maximum real-time sample rate and 25GSa/s equivalent time sample rate
- 5.6” TFT QVGA (320X240) with 64K color LCD backlighted display
- 16 channels logic analyzer, mixed test, pattern cursor test and data memory
- Trigger modes: edge, pulse width, slope, video, pattern, continuous time, alternate trigger
- Multiple interface configurations: Standard USB Host and USB device, RS-232 and support U disk storage and PictBridge print standards, optional USB-GPIB adapter
- easy user interface
- low price
Details:
| Specification | |
|---|---|
| Channels | 2 |
| Bandwith | 50 MHz (DS1052D) | 100MHz (DS1102D) |
| Sample Rate | 1GSa/s (half chanel), 500MSa/s (each chanel) |
| Logic-Analyzer | 16 Channel |
| Input Coupling | DC, AC, GND |
| Input Impedance | 1MOhm±2%, the input capacity is 18pF±3pF |
| A/D Converter | 8-bit resolution, all channels sample simultaneously |
| Volts/div Range | 2mV/div~10V/div (at the input terminal connecting to BNC) |
| Maximum Input |
Maximum input voltage on analog channel CAT I 300Vrms, 1000Vpk; instantaneous overvoltage 1000Vpk CAT II 100Vrms, 1000Vpk RP2200 10:1, CAT II 300Vrms RP3200 10:1, CAT II 300Vrms RP3300 10:1, CAT II 300Vrms |
| Offset Range |
±40V (250mV/div~10V/div) ±2V (2mV/div~245mV/div) |
| Trigger Modes | edge, pulse width, slope, video, alternate trigger |
| Display Type | 145mm (5.6 inch) diagonal TFT Liquid Crystal Display |
| Display Resolution | 320 horizontal ×RGB×234 vertical pixels |
| Display Color | 64k color |
| Display Contrast | 150:1 (typical) |
| Backlight Brightness | 300 nit (typical) |
| Supply Voltage | 100 ~ 240VAC, 45~440Hz, CAT II |
| Power Consumption | Less than 50W |
| Fuse | 2A, T rating, 250 V |
| Product Dimension | 303x154x133mm |
| Product Weight | 2.3kg |
For more information, specification and function please check the datasheet.
Package Content:
| Quantity | Content |
|---|---|
| 2 | Passive Probes (1.5m) (1:1 or 10:1 adjustable) |
| 1 | Power Cord (please select above for which country) |
| 1 | USB Cable |
| 1 | CD-ROM (including User's Guide and Application Software) |
| 1 | Quick Guide |
